Used YAMA SEIKI GLS-1500 | Lathe - 2-axis
Have one to sell?
ConditionUsed
1 available
With the latest machine tools technology and precision turning performance, GOODWAY brings you the new GLS-1500 series high-speed CNC turning center. Using 2 types of bed combined with super rigidity, high-speed turning capability and compact size provides you with super efficiency cutting power. The GLS-1500 series equipped with an optional live tooling turret, Y-axis and sub-spindle can work on turning, milling, drilling tasks at the same time to increase the output capacity with high end value to meet your needs of today and tomorrow.
Key Features:
✔ 30˚ slant-bed design provides smooth chip disposal and easier operator access.
✔ Steel way covers and special steel wipers molded with industrial-strength rubber are used for durability.
✔ Fully enclosed splash guards keep chips and coolant contained for a safe clean working environment.
✔ The auto lubrication system delivers metered amounts of lubrication to the slideways, ball screws, and vital components. Distribution is automatically shut off during idling to prevent waste.
Yama Seiki GLS-1500 / 2000 CNC Turning Center (Chucker Version)
Base package features & accessories
1. Fanuc 0i-T Control with 10.4" Color LCD
2. Fanuc Alpha Spindle & Servo Drives
3. Fanuc AC 15 HP (Cont.), 20 HP (30 min.), 25 HP (Peak) Dual Winding Spindle Motor
4. Single Spindle Speed Configuration
5. Direct Belt Driven Spindle
6. Max Turning Length: 12.20” (310 mm)
7. Main Spindle RPM
a. GLS-1500 - 20 ~ 6,000 RPM
b. GLS-2000 - 20 ~ 4,500 RPM
8. Chuck including One Set of Soft Jaws
a. GLS-1500 – 6 inch 3-Jaw Through-Hole (52 mm) BIG-BORE Power Chuck
b. GLS-2000 – 8 inch 3-Jaw Through-Hole (65 mm) BIG-BORE Power Chuck
9. 12 Station Standard Servo Indexing Turret with 1” OD and 1-1/2” ID Tooling Shank
10. X/Z Axis Fanuc AC 4.0 HP Servo Motor with Absolute Encoder
11. Guide Way: Linear Guide Ways
12. No Tailstock (optional)
13. Grundfos 94 PSI High Pressure Coolant Pump (MTH 2-50/5) with Roll-Out Coolant Tank
14. Operation & Maintenance Manuals, Parts List, Electrical Drawings and Factory Test Report
15. Three Color Operation Status Signal Light Tower
16. Tool Box with Emergency Maintenance Electrical Part Package
17. Standard Tool Holder and Sleeves Package
18. Safety Features: Fully Enclosed Guarding, Door Interlock, Hydraulic Pressure Safety Switch, Program Protect, Chuck Clamp/Unclamp Confirmation
