New YAMA SEIKI BM-1500 | Vertical Mill - 3-Axis
Have one to sell?
ConditionNew
New
Yama Seiki brings the Ultimate Machining Power without the ultimate price. All the machine in our lineup are built based on the latest Japanese Technologies and components and manufactured under strict ISO 9001 and 14001 regulations. Knowing that the complexity of present and future machining processes require more capable and reliable machines, we offer you the Yama Seiki Advantage.
Designed with heavy-duty performance and practicality in mind, the BM1500-II offers power, strength and speed to accomplish today’s toughest machining applications. The 4 box ways on Y-axis design provides a super rigid foundation to ensure heavy-duty cutting capabilities. The spindle is powered by a Fanuc alpha 15i 20/25/40HP (CONT./30min./PEAK) AC spindle motor. New features include a 24, 30 or 40 tool swing arm tool changer, box ways on all axes, 40 taper (15,000RPM) or 50 taper (6,000RPM) spindle, spindle oil chiller, chip wash down, chip conveyor, enclosed splash guard, and much more. A Direct Driven (40 Taper), or 2-speed heavy-duty geared spindle (50 Taper) is also standard, generating the power needed to tackle the toughest of materials
Machine Specifications:
1. Table Size: 63” x 27.6” (1600 x 700mm)
2. XYZ Travels: 59” x 29.1” x 24” (1,500 x 740 x 610mm)
3. Spindle Speed: 6,000 RPM
4. Spindle Type: TRUE GEAR HEAD (2-STEP)
5. Spindle Taper: CAT-50, Dual Contact Spindle System
6. Spindle Motor: FANUC ALPHA 15i SPINDLE MOTOR, 20/25/40 HP (Cont./30min/Peak)
7. Tool Magazine Capacity: 30 Tools Magazine Side Mount Arm Type
Control options included:
1. Fanuc 0i-MF Control PLUS with 10.4” Color LCD
2. Parts Program Storage Size Upgrade to 2MB
3. Max Number of Registerable Programs Upgrade 1000
4. Fanuc AI Contour Control II (200 Block Look-Ahead)
5. Dynamic Graphic Display
6. Jerk Control
7. Smooth Tolerance Control
8. Manual Handle Retrace
9. One Touch Macro Call
10. Fanuc “MANUAL GUIDE-I” CONVERSATIONAL PROGRAMMING
11. AWEA “I-Console” Intelligent Software
12. Rigid Tapping
13. Ethernet/LAN/RS232/USB/Memory Card
Options equipped:
1. Machine Performance Package:
2. UPGRADE Z Axis Motor Drive the Whole Weight of The Spindle Head
3. Spindle Oil Chiller
4. Coolant Thru Spindle 1000 PSI Prep (W/ Union)
5. 300 PSI High Pressure Coolant System
6. Caterpillar Type Chip Conveyor
7. 3-Color Tower Light
8. Coolant and Air Gun
9. Air Buffer Tank for ATC Tool Change
10. Additional High-Intensity Lighting Internally Mounted LED Lights
11. Air Curtain Around Spindle
12. Coolant Nozzle Around Spindle
13. Hardened And Ground Box Ways
14. Hardened C3 Class Ball Screws
15. High Intensity Work Light
16. M Code Controlled Air Blow
17. M Code Automatic Power Off
18. Coolant Wash Down
19. Coolant System with Grundfos 3/4hp Coolant Pump
20. Enlarged 500 Liter (131 Gallon) Coolant Tank
21. Full Enclosed Splash Guard
22. Dual Internal Chip Auger
23. Advance Auto Lubrication System W/ Copper Piping
24. Way Lubrication Oil Recycling System
25. Remote MPG Handwheel
26. Electrical Cabinet Heat Exchanger
27. Leveling Kit
28. Electronic User’s Manuals (Operation and Maintenance Manuals, Parts List, Electrical Drawing) And Factory Test Report
29. Safety Features: Full Roof Enclosure Splash Guard, Door Interlock, Safety Switch, Program Protect
30. Fanuc Control and Components Limited Warranty – 2 Years
31. Machine Limited Warranty – 1 Year
ADDED OPTIONS
4TH AXIS INTERFACE
Renishaw OMI-2T Interface
